Metal Temperature Sensor (MTS)
Technology: Sensing
Product Category: Temperature Sensors
Application: Transportation
Brand: Therm-O-Disc
Metal Temperature Sensor (MTS) measures the temperature of metal such as cylinder heads for internal combustion engines. Can also be used to measure other media – please check with a Sensience Sales Representative for any specific
applications.
- Durability: We utilize single-step molding for lower complexity and better moisture
intrusion resistance - Accuracy: Our sensors are accurate – up to 1% for critical temperatures
- Response Time: Our sensors are up to 2x faster than competitors in response time
| Sensor Type: | Temperature, Thermistor, NTC Type |
| Output Options: | Analog |
| Installation: | Screw in |
| Supply Voltage: | 5 VDC, pull-up resistor required |
| Operating Temperature Range: | -40C to 150C for connector, up to 250C at sensor tip. |
| Sensor Output Accuracy: | ±3% Typical, as narrow as ±1% at key temperatures. |
| Thermal Time Constant T63: | As low as 2 seconds in water |
| Ingress Protection (IP) Code: | IP6K9K & IPx7 |
| Long Term Stability: | < 3% drift over life |
- Shell material: Stainless Steel, Brass, Aluminum
- Shell interface: Threaded install (hex 10 to hex 19)
- Integrated Connector: two pin standard USCAR sealed connection (in-line or 90°), using
PA66 or PPS resins - Lead Wire Type Connector Strategy Also Available
